Proximity Reader with mobile credentials
NFC® and Bluetooth® - NODER MDB-R / NODER MDKB-R
Key features:
Downloads:
Description
Multidimensional flexibility
Proximity Reader with Mobile Credentials designed for modern access control systems. The NODER MDB-R and NODER MDKB-R readers combine secure RFID, NFC® and Bluetooth® mobile credentials with an ultra-slim 1.5 cm profile. Forget about compromising between advanced technology and aesthetics. Our readers provide reliable, contactless access while blending seamlessly into any environment. Designed for places where every detail matters. We believe that security systems do not have to be conspicuous or disrupt a carefully planned interior design. Thanks to extensive customisation options, you have complete freedom to create a cohesive look for your space. Whether you want the device to harmonise perfectly with your chosen electrical fittings or to blend discreetly into the colour of the wall or façade, this reader will adapt to your vision. You receive a bespoke solution in which reliable functionality goes hand in hand with impeccable design. The reader’s front panel is manufactured using technology that prevents unsightly fingerprints and ensures the device retains its pristine appearance even with heavy use.
Safety and flexibility
Our proximity reader with mobile credentials supports the latest identification standards, including MIFARE DESFire technology and mobile technologies. It guarantees full data protection thanks to encrypted RS485 communication (AES256).
Its compact dimensions and modern design allow for hassle-free installation on most standard profiles and door frames, whilst its IP54 rating ensures resistance to dust and splashes. As a result, the MDB-R is ideal not only for prestigious lobbies and offices, but also for areas with high humidity or high levels of dust.
This reader allows you to
use your smartphone to open doors!
Proximity reader with mobile credentials
When used with the NODER Mobile Access app and the NODER Virtual Access Card, the mobile access reader enables authorisation directly from iOS- and Android-based smartphones. This solution makes it possible to reduce, or even completely eliminate, the need to issue and carry traditional, physical RFID cards.
Are you wondering whether this is a secure solution? Be sure to read the article “Virtual cards versus physical cards: Mobile credentials in NODER access control”.
The reader was designed and manufactured entirely in European Union.
Security of the highest standard, regardless of the authentication method
The reader uses advanced encryption at every stage of communication:
- when exchanging data with controllers,
- when reading physical MIFARE DESFire cards,
- when connecting to the NODER mobile Virtual Access Card.
Strength
The housing of the MDB-R and MDKB-R readers are the same and is made from high-quality ASA (Acrylonitrile-Styrene-Acrylate) plastic. This is an advanced engineering polymer which, in terms of mechanical properties, is similar to the widely used ABS, but significantly outperforms it in terms of resistance to external factors.
Personalisation
Customise the readers to suit your needs
Our proximity readers with mobile credentials are available as standard in black with a black front; customisation allows for changes and special finishes within the following range:
ST version
The default housing and front design is black.
The ST version of the reader is available with a black body and a black matt front panels or keypads. It is the perfect solution for most access control systems.
FLEX version
The housing and front are available in separate designs. Based on the RAL Classic colour chart.
The Flex version is available in any of the 216 colours from the RAL Classic colour chart. The colour of the front of the reader can be customised to blend in with the architecture.
ARTEA version
The housing is available in the following design: Based on the RAL Classic colour chart. The front design is based on the Fundermax® HPL chart.
The Artea version is available in any of the 216 colours from the RAL Classic colour chart. The front of the reader is made of HPL, allowing to choose a pattern and colour that perfectly matches your interior design.
Characteristics
| SUPPORTED TECHNOLOGIES | MIFARE Classic® / MIFARE DESFire® / NFC® / Bluetooth ® |
| MOBILE CREDENTIALS | NFC® and Bluetooth ® via the NODER Mobile Access app |
| COMMUNICATION INTERFACE | RS-485 (encrypted) |
| ENCRYPTION OF COMMUNICATIONS WITH A PHYSICAL CARD | AES-128 |
| ENCRYPTION OF COMMUNICATIONS WITH A VIRTUAL CARD | AES-128 |
| ENCRYPTION OF COMMUNICATIONS WITH THE CONTROLLER | AES-256 |
technical specification
| HOUSING COLOUR |
The standard ST version is available in black. Customisation options are available. |
| INSTALLATION | Surface-mounted |
| DISTANCE FROM THE CONTROLLER | Up to 1000m (without power supply) |
| SIGNALLING | LEDs with programmable dimming capability, buzzer |
| BACKLIGHT | Positioning the backlight of the MDKB-R reader |
| TAMPER | Yes, optical sensor for detecting separation from the wall and opening of the housing |
| IP PROTECTION |
IP65 for version (z) IP51 for version (w) |
| DATA CONNECTOR | 50cm pigtail |
| SUPPLY VOLTAGE | 10-15V DC |
| POWER CONSUMPTION | ~100mA, max 150mA |
| WEIGHT |
105g for version (w) 125g for version (z) |
| OPERATING TEMPERATURE | -40°C – +65°C |
| DIMENSIONS |
height x width x depth 102 x 67.5 x 15.5 mm 102 x 67.5 x 35.5 mm with additional spacer |
| CERTIFICATES | CE, RoHs, EMC, LVD |
Available models
| MDB-R (z) |
Mobile Proximity Reader. Designed for outdoor installation. |
| MDB-R (w) |
Mobile Proximity Reader. Designed for indoor installation. |
| MDBK-R (z) |
Mobile Proximity Reader with Keypad. Designed for outdoor installation. |
| MDBK-R (w) |
Mobile Proximity Reader with Keypad. Designed for indoor installation. |
downloadS
